The equipment was development by AO NPP VNIIGIS in cooperation with OOO NPC ECO-Technology Foundation
SCOPE OF APPLICATION
Designed for cement quality control and technical condition of oil and gas, hydrogeological and other wells, equipped with casing and tubing with an inside diameter from 73 to 200 mm, as well as for logging of open hole wells by travel time and dynamic parameters of elastic waves
FEATURES AND ADVANTAGES
- increased response to cement ring defects of bulk and contact type;
- detecting the location of the drilling tool sticking and the position of tubing shoe;
- the ability to work with digital stations (such as HECTOR and VULCAN).
Specifications
| Probe scheme | T20,25T11,5R |
| Max.hydrostatic pressure, MPpa | 80 (100) |
| Max.temperature rating, °C | 120 (150) |
| Required power, W | 30 |
| Overall dimensions of tool, mm diameter (without centralizers) length | 48 3100 |
| Number of cores used, pcs | 1 |
| Weight of downhole tool, kg | 20 |
Note: The equipment of controlled radiating power is possible.
